دیتاشیت TO220B03 Pkg Drawing

TO220B03 Pkg Drawing

مشخصات دیتاشیت

نام دیتاشیت TO220B03 Pkg Drawing
حجم فایل 99.003 کیلوبایت
نوع فایل pdf
تعداد صفحات 1

TO220B03 Pkg Drawing

دانلود دیتاشیت

سایر مستندات

TIP102 4 pages

TIP100-102,105-07 7 pages

مشخصات فنی

  • RoHS: true
  • Category: Triode/MOS Tube/Transistor/Darlington Transistors
  • Package: TO-220
  • Manufacturer: SPTECH
  • Datasheet: STMicroelectronics TIP107
  • Transistor Type: PNP
  • Operating Temperature: +150°C@(Tj)
  • Collector Current (Ic): 8A
  • Power Dissipation (Pd): 2W
  • Transition frequency (fT): -
  • DC current gain (hFE@Vce,Ic): 1000@4V,3A
  • Collector-emitter voltage (Vceo): 100V
  • Collector cut-off current (Icbo@Vcb): 50uA
  • Collector-emitter saturation voltage (VCE(sat)@Ic,Ib): 2.5V@8A,80mA
  • Series: -
  • Packaging: Tube
  • Part Status: Obsolete
  • Current - Collector (Ic) (Max): 8A
  • Voltage - Collector Emitter Breakdown (Max): 100V
  • Vce Saturation (Max) @ Ib, Ic: 2.5V @ 80mA, 8A
  • Current - Collector Cutoff (Max): 50µA
  • DC Current Gain (hFE) (Min) @ Ic, Vce: 1000 @ 3A, 4V
  • Power - Max: 2W
  • Frequency - Transition: -
  • Mounting Type: Through Hole
  • Package / Case: TO-220-3
  • Supplier Device Package: TO-220AB
  • Base Part Number: TIP107
