دیتاشیت FDP6030BL
مشخصات دیتاشیت
| نام دیتاشیت | FDB6030BL, FDP6030BL |
|---|---|
| حجم فایل | 384.2 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 5 |
دانلود دیتاشیت FDB6030BL, FDP6030BL |
FDB6030BL, FDP6030BL Datasheet |
|---|
مشخصات
- Manufacturer: ON Semiconductor
- Series: PowerTrench®
- Packaging: Tube
- Part Status: Active
- FET Type: N-Channel
- Technology: MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss): 30V
- Current - Continuous Drain (Id) @ 25°C: 40A (Tc)
- Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
- Rds On (Max) @ Id, Vgs: 18mOhm @ 20A, 10V
- Vgs(th) (Max) @ Id: 3V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs: 17nC @ 5V
- Vgs (Max): ±20V
- Input Capacitance (Ciss) (Max) @ Vds: 1160pF @ 15V
- FET Feature: -
- Power Dissipation (Max): 60W (Tc)
- Operating Temperature: -65°C ~ 175°C (TJ)
- Mounting Type: Through Hole
- Supplier Device Package: TO-220-3
- Package / Case: TO-220-3
- Base Part Number: FDP60
- detail: N-Channel 30V 40A (Tc) 60W (Tc) Through Hole TO-220-3
