دیتاشیت HUF75545P3

HUF75545P3, HUF75545S3S

مشخصات دیتاشیت

نام دیتاشیت HUF75545P3, HUF75545S3S
حجم فایل 825.106 کیلوبایت
نوع فایل pdf
تعداد صفحات 10

دانلود دیتاشیت HUF75545P3, HUF75545S3S

HUF75545P3, HUF75545S3S Datasheet

مشخصات

  • Manufacturer: ON Semiconductor
  • Series: UltraFET™
  • Packaging: Tube
  • Part Status: Active
  • FET Type: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 80V
  • Current - Continuous Drain (Id) @ 25°C: 75A (Tc)
  • Drive Voltage (Max Rds On, Min Rds On): 10V
  • Rds On (Max) @ Id, Vgs: 10mOhm @ 75A, 10V
  • Vgs(th) (Max) @ Id: 4V @ 250µA
  • Gate Charge (Qg) (Max) @ Vgs: 235nC @ 20V
  • Vgs (Max): ±20V
  • Input Capacitance (Ciss) (Max) @ Vds: 3750pF @ 25V
  • FET Feature: -
  • Power Dissipation (Max): 270W (Tc)
  • Operating Temperature: -55°C ~ 175°C (TJ)
  • Mounting Type: Through Hole
  • Supplier Device Package: TO-220-3
  • Package / Case: TO-220-3
  • Base Part Number: HUF75
  • detail: N-Channel 80V 75A (Tc) 270W (Tc) Through Hole TO-220-3
