دیتاشیت MCH6445-TL-W
مشخصات دیتاشیت
| نام دیتاشیت |
MCH6445
|
| حجم فایل |
1046.134
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
5
|
مشخصات
-
Manufacturer:
ON Semiconductor
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
FET Type:
N-Channel
-
Technology:
MOSFET (Metal Oxide)
-
Drain to Source Voltage (Vdss):
60V
-
Current - Continuous Drain (Id) @ 25°C:
4A (Ta)
-
Drive Voltage (Max Rds On, Min Rds On):
4V, 10V
-
Rds On (Max) @ Id, Vgs:
78mOhm @ 2A, 10V
-
Vgs(th) (Max) @ Id:
-
-
Gate Charge (Qg) (Max) @ Vgs:
10nC @ 10V
-
Vgs (Max):
±20V
-
Input Capacitance (Ciss) (Max) @ Vds:
505pF @ 20V
-
FET Feature:
-
-
Power Dissipation (Max):
1.5W (Ta)
-
Operating Temperature:
150°C (TJ)
-
Mounting Type:
Surface Mount
-
Supplier Device Package:
6-MCPH
-
Package / Case:
6-SMD, Flat Leads
-
Base Part Number:
MCH64
-
detail:
N-Channel 60V 4A (Ta) 1.5W (Ta) Surface Mount 6-MCPH
