دیتاشیت MCH6663-TL-W
مشخصات دیتاشیت
| نام دیتاشیت |
MCH6663
|
| حجم فایل |
663.446
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
7
|
مشخصات
-
RoHS:
true
-
Type:
-
-
Category:
Triode/MOS Tube/Transistor/MOSFETs
-
Operating Temperature:
-55°C~+150°C@(Tj)
-
Power Dissipation (Pd):
800mW
-
Total Gate Charge (Qg@Vgs):
2nC@10V
-
Drain Source Voltage (Vdss):
30V
-
Input Capacitance (Ciss@Vds):
88pF@10V
-
Continuous Drain Current (Id):
1.8A;1.5A
-
Gate Threshold Voltage (Vgs(th)@Id):
2.6V@1mA
-
Reverse Transfer Capacitance (Crss@Vds):
-
-
Drain Source On Resistance (RDS(on)@Vgs,Id):
188mΩ@900mA,10V
-
Package:
SC-88(MCPH6)
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
FET Type:
N and P-Channel
-
FET Feature:
Logic Level Gate, 4V Drive
-
Drain to Source Voltage (Vdss):
30V
-
Current - Continuous Drain (Id) @ 25°C:
1.8A, 1.5A
-
Rds On (Max) @ Id, Vgs:
188mOhm @ 900mA, 10V
-
Vgs(th) (Max) @ Id:
2.6V @ 1mA
-
Gate Charge (Qg) (Max) @ Vgs:
2nC @ 10V
-
Input Capacitance (Ciss) (Max) @ Vds:
88pF @ 10V
-
Power - Max:
800mW
-
Mounting Type:
Surface Mount
-
Package / Case:
6-SMD, Flat Leads
-
Supplier Device Package:
SC-88FL/MCPH6
-
Base Part Number:
MCH66
-
detail:
Mosfet Array N and P-Channel 30V 1.8A, 1.5A 800mW Surface Mount SC-88FL/MCPH6
